#include<iostream.h>
#include<stdio.h>
#include<conio.h>
#include<stdlib.h>
#include<float.h>
#include<math.h>
#include<iomanip.h>
/*printcomplexnumber(double real,double imag)
{
if (real==0)
cout<<imag<<"i";
if (imag<0)
cout<<real<<imag<<"i";
if (imag > 0)
cout<<real<< "+"<<imag<<"i";
if (imag==0)
cout<<real;
return(real,imag); } */
int main()
{ double Ex[9][9][9][9],Ey[9][9][9][9],Ez[9][9][9][9];
double Hy[9][9][9][9],Hx[9][9][9][9],Hz[9][9][9][9];
int i,j,k,n,imax,jmax,kmax,nmax;
float A,ep[10][10][10],eo,muo;
float dt,c,w,t,lamda;
cout<<"enter the limits for space and time\n";
cin>>imax;
cin>>jmax;
cin>>kmax;
cin>>nmax;
/*to assign the dielectric constant*/
for(i=0;i<=imax;i++)
{for(j=0;j<=jmax;j++)
{for(k=0;k<=kmax;k++)
{if((i<=imax/2)&&(j<=jmax/2)&&(j<=jmax/2))
ep[i][j][k]=1;
else
ep[i][j][k]=12;
}/*kloop*/
}/*j loop*/
}/*i loop
/* to check the dielectric constant of space*/
cout<<"enter the value of x,y,z\n";
cin>>i;
cin>>j;
cin>>k;
cout<<"the dielectric constant at this point is ="<<ep[i][j][k]<<endl;
/*to clear the memor/
for(n=0;n<=nmax;n=n++)
{
for(i=0;i<=imax;i++)
{for(j=0;j<=jmax;j++)
{for(k=0;k<=kmax;k++)
{Ex[i][j][k][n]=0;
Ey[i][j][k][n]=0;
Ez[i][j][k][n]=0;
Hx[i][j][k][n]=0;
Hy[i][j][k][n]=0;
Hz[i][j][k][n]=0;
}/*k loop/
}/*j loop /
}/*i loop /
}/* t loop/
/* launching incident plane wave propagating in x dir*/
cout<<"\n enter the A and lamda(in micron)";
cin>>A;
cin>>lamda;
c=3e8;
w=(2*3.14*c)/lamda;
dt=1e-15;
cout<<"i j k n field value"<<endl;
for(n=1;n<=2;n++)
{for(i=0;i<=imax;i++)
{for(j=0;j<=jmax;j++)
{for(k=0;k<=kmax;k++)
{t=n*dt;
Ex[i][j][k][n]=A*sin(w*t);
Ey[i][j][k][n]=A*sin(w*t);
Ez[i][j][k][n]=A*sin(w*t);
Hx[i][j][k][n]=A*sin(w*t);
Hy[i][j][k][n]=A*sin(w*t);
Hz[i][j][k][n]=A*sin(w*t);
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Hz"<<"\t"<<Hz[i][j][k][n]<<endl;
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Hx"<<"\t"<<Hx[i][j][k][n]<<endl;
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Hy"<<"\t"<<Hy[i][j][k][n]<<endl;
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Ez"<<"\t"<<Ez[i][j][k][n]<<endl;
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Ey"<<"\t"<<Ey[i][j][k][n]<<endl;
cout<<i<<"\t"<<j<<"\t"<<k<<"\t"<<n<<"\t"<<"Ez"<<"\t"<<Ex[i][j][k][n]<<endl;
}/* k loop*/
}/* j loop*/
}/* i loop*/
}/*t loop*/
eo=8.85e-12;
muo=12.56e-7;
/*boundary condition*/
/*implememnting the FDTD ie.,leap frog method*/
for(n=2;n<=nmax-1;n++)
{for(i=2;i<=imax-2;i++)
{for(j=2;j<=jmax-2;j++)
{for(k=2;k<=kmax-2;k++)
{Hx[i][j][k][n+1]=Hx[i][j][k][n-1]+(1/muo)*(Ey[i][j][k+1][n]-Ey[i][j][k][n])-(1/muo)*(Ez[i][j+1][k][n]-Ez[i][j][k][n]);
Hy[i][j][k][n+1]=Hx[i][j][k][n-1]+(1/muo)*(Ez[i+1][j][k][n]-Ez[i][j][k][n])-(1/muo)*(Ex[i][j][k+1][n]-Ex[i][j][k][n]);
Hx[i][j][k][n+1]=Hx[i][j][k][n-1]+(1/muo)*(Ex[i][j+1][k][n]-Ex[i][j][k][n])-(1/muo)*(Ey[i+1][j][k][n]-Ey[i][j][k][n]);
Ex[i][j][k][n+1]=Ex[i][j][k][n-1]+(1/eo)*(Hz[i][j][k][n]-Hz[i][j-1][k][n])-(1/eo)*(Hy[i][j][k][n]-Hy[i][j][k-1][n]);
Ey[i][j][k][n+1]=Ex[i][j][k][n-1]+(1/eo)*(Hx[i][j][k][n]-Hx[i][j][k-1][n])-(1/eo)*(Hz[i][j][k][n]-Hz[i-1][j][k][n]);
Ez[i][j][k][n+1]=Ex[i][j][k][n-1]+(1/eo)*(Hy[i][j][k][n]-Hy[i-1][j][k][n])-(1/eo)*(Hx[i][j][k][n]-Hx[i][j-1][k][n]);
cout<<Ez[i][j][k][n+1]; }/* k loop*/
}/*j loop*/
} /*i loop*/
}/*t loop*/
return 0; }/*main end*/
|
