Exchange not working over VPN

Zones: SBS Small Business Server, Virtual Private Networking (VPN)

Tags: Microsoft, SBS, 2003 R2

I have a North and South office connect with a Linksys VPN, SBS 2003 is at the North office.
Users from either site can ping the gateways and public IP's from the local and remote sites to verify the VPN is working. Either site can type \\server name in Windows explorer and see file and printer resources at either site. Users at the South office can log into the SBS domain without any isuses.
Company Web, the internal SBS site can be seen from either site as well.

There are two things that are not accessable:
1) Remote Web Workplace - Logging into the SBS with RWW you can access any resources including the South 2003 Std Server, but you can not access any client machines. They are not available.

2) We can not set up Outlook, they can only access email using the Web interface. If I enter the Exchange server into the mail setup it gives me an error saying it can not find the server or account.

I am thinking the two problems are related by a DNS issues but not sure what entry to make or where it needs to be. I have DNS entries for both servers on the two servers which got everything working this far. Any suggestions would be appreciated.

Attachments:

Network-Diagram.pdf (231 KB) (File Type Details)

Network Diagram of SBS

Start your free trial to view this solution

[x]

The Solution Rating System

With so many solutions, how can you tell which solutions are most likely to help you and which ones are not? To provide you with a tool to use, we rate our solutions based on various elements that most accurately determine if a solution is a quality solution. To explain what factors affect the solution rating, here are the elements we take into consideration when formulating our solution rating.

The Grade of the Solution
The Zone Rank of the Expert Providing the Solution
The Number of Author and Expert Comments
The Number of Experts Contributing
The Feedback of the Community

Your Input Matters
Because of the way the system is set up, the most important variable in this equation is you. As a member of Experts Exchange, you are able to cast your vote on the quality of the solutions in regard to how complete, accurate, helpful and easy to understand each solution is. When you provide your feedback, each rating is adjusted accordingly. So, if you see a solution that has a poor rating that you think is a good solution, let us know by rating it. As you do, the rating will be adjusted and will become more accurate for other members of our site.

If you have any suggestions that you would like to make for our rating system, please ask a question in the Suggestions Zone of Community Support.

Thank you!

6.4

Question Stats

Zone: OS

Question Asked By: richlang

Solution Provided By: richlang

Participating Experts: 2

Solution Grade: A

Translate:

Loading Advertisement...

Open Discussion

Comment by billy_Lunam

This string is quite long and i need new glasses, so hope I have not missed the point.
As the outlook web access (OWA) works. Try setting up the outlook clients as RPC over HTTP (Outlook Anywhere) as a work around. You may need to trat them as none domain PCs in doing so.

On one of your south PC's use the LMHosts file with Pre and DOM commands, in that file add the details for both servers. Reboot and test that PC. It may help ID where this is going wrong

Bill Lunam
