Question

Need help creating a mask using ActionScript 3.0

Asked by: dyarosh

I am new to Flash and am trying to do something that I think should be simple.  I am loading pictures from an XML file using AS3.  What I want to do is to put an irregular border around the picture and show only the part of the picture that is within the border.

When I was testing this I started by putting a picture on the stage on a layer and then putting the border on another layer and setting the layer as a mask.  The picture displayed the way I wanted.

Now I'm loading the picture dynamically onto the stage and want to apply the mask but I can't figure out how to do it.  Any help would be greatly appreciated.

In the code below, picMask is a movieclip on the stage that has the border in it.

import fl.transitions.Tween;
import fl.transitions.easing.*;

var imageX:XML;
var imageList:XMLList;
var preload:preloader = new preloader();
var sortArray:Array = new Array();
var zSpacing:Number = 0;
var currentImage:Number;
var currentMaskee:MovieClip;
var currentMask:MovieClip;

var picTimer:Timer = new Timer(5000);
picTimer.addEventListener(TimerEvent.TIMER, nextPic);

var images_mc:MovieClip = new MovieClip();
images_mc.visible = false;
addChild(images_mc);
var req:URLRequest = new URLRequest("images.xml");
var imageLoader:URLLoader = new URLLoader();
imageLoader.addEventListener(Event.COMPLETE, onComplete);
imageLoader.load(req);
root.transform.perspectiveProjection.projectionCenter = new Point(0,0);

function onComplete(e:Event):void
{
	imageX = new XML(imageLoader.data);
	imageList = new XMLList(imageX.image);
	for (var i:uint=0; i < imageList.length(); i++)
	{
		var pic:Picture = new Picture(imageList[i].url);
		pic.x = 0;
		pic.y = 0;
		pic.z = i * zSpacing;
		images_mc.addChild(pic);
		sortArray.push(pic);
	}

	sortArray.sortOn("z", Array.NUMERIC | Array.DESCENDING);
	for (var j:uint = 0; j<sortArray.length; j++)
	{
		images_mc.setChildIndex(sortArray[j],j);
	}
	currentImage = sortArray.length - 1;
	preload.x = stage.stageWidth/2 - preload.width/2;
	preload.y = stage.stageHeight/2 - preload.height/2;
	preload.bar_mc.scaleX = 0;
	addChild(preload);
	preload.addEventListener(Event.ENTER_FRAME, preloading);
}

function preloading(e:Event):void
{
	var totalPct:Number = 0;
	for (var i:uint = 0; i < sortArray.length; i++)
	{
		totalPct += sortArray[i].pctLoaded;
	}
	var avg:Number = totalPct / sortArray.length;
	preload.bar_mc.scaleX = avg;

	if (avg >= 1)
	{
		images_mc.visible = true;
		images_mc.mask(picMask);
		preload.removeEventListener(Event.ENTER_FRAME, preloading);
		removeChild(preload);

		// Change pictures every 5 seconds
		picTimer.start();

	}
}

function maskPicture(e:Event):void
{
	images_mc.mask(picMask);

}

function nextPic(e:TimerEvent):void
{
	for (var i:uint=0; i<sortArray.length; i++)
	{
		if (i == currentImage)
		{
			sortArray[i].z = (sortArray.length-1)*zSpacing;
			images_mc.setChildIndex(sortArray[i],0);
		}
		else
		{
			var startZ:Number = sortArray[i].z;
			var endZ:Number = startZ - zSpacing;
			new Tween(sortArray[i],"z",Regular.easeOut,startZ,endZ,12,false);
		}
	}
	if (currentImage > 0)
	{
		currentImage--;
	}
	else
	{
		currentImage = sortArray.length - 1;
	}
}

function onTick(event:TimerEvent):void
{
	// displays the tick count so far
    // The target of this event is the Timer instance itself.
    trace("tick " + event.target.currentCount);
}


1:
2:
3:
4:
5:
6:
7:
8:
9:
10:
11:
12:
13:
14:
15:
16:
17:
18:
19:
20:
21:
22:
23:
24:
25:
26:
27:
28:
29:
30:
31:
32:
33:
34:
35:
36:
37:
38:
39:
40:
41:
42:
43:
44:
45:
46:
47:
48:
49:
50:
51:
52:
53:
54:
55:
56:
57:
58:
59:
60:
61:
62:
63:
64:
65:
66:
67:
68:
69:
70:
71:
72:
73:
74:
75:
76:
77:
78:
79:
80:
81:
82:
83:
84:
85:
86:
87:
88:
89:
90:
91:
92:
93:
94:
95:
96:
97:
98:
99:
100:
101:
102:
103:
104:
105:
106:
107:
108:
109:
110:
111:
112:

Select allOpen in new window

This Question has been solved and asker verified All Experts Exchange premium technology solutions are available to subscription members.

Subscribe now for full access to Experts Exchange and get

Instant Access to this Solution

  • Plus...
  • 30 Day FREE access, no risk, no obligation
  • Collaborate with the world's top tech experts
  • Unlimited access to our exclusive solution database
  • Never be left without tech help again

Subscribe Now

Asked On
2009-10-03 at 16:44:57ID24783021
Topics

ActionScript

,

Adobe Flash

,

Web Development

,

Web Development Software

Participating Experts
1
Points
500
Comments
11

Trusted by hundreds of thousands everyday for fast, accurate and reliable tech support.

  • "The time we save is the biggest benefit of Experts Exchange to Warner Bros. What could take multiple guys 2 hours or more each to find is accessed in around 15 minutes on Experts Exchange." Mike Kapnisakis, Warner Bros.
  • "Our team likes having a resource that is more secure than just using Google and most experts using this service really know their stuff. It's nice to look here first versus using Google." Dayna Sellner, Lockheed Martin
  • "Anytime that I've been stumped with a problem, 9 out of 10 times Experts Exchange has either the accepted solution or an open discussion of the potential solution to the problem." Kenny Red, eBay Inc.

See what Experts Exchange can do for you.

Got a question?

We've got the answer.

Experts Exchange has been collecting answers to technology questions since 1996…3 million and counting! If you have a question, chances are we already have your answer.

Screenshot of Experts Exchange Knowledgebase

Need individual assistance?

Our experts are ready to help.

If you can't find the exact answer you're looking for, ask our exclusive community of 50,000 experts. You’ll get a personalized answer from a trusted professional.

Screenshot of Experts Exchange Knowledgebase

Want to learn from the best?

Read articles from industry experts.

Thousands of free tech tips, tricks, how-to’s and tutorials are available in our peer reviewed articles section. See for yourself how smart our experts are, no login required.

Screenshot of an Article

Working on a long term project?

Store your work and research.

Save solutions to your questions, answers you’ve discovered through searching plus helpful articles in your personal knowledgebase for easy future access.

Screenshot of Experts Exchange Knowledgebase

Access the answers to your technology questions today.

Subscribe Now

30-day free trial. Register in 60 seconds.

What Makes Experts Exchange Unique?

Members of the expert community talk about why the experience at Experts Exchange is different than what you will find anywhere else.

Trusted by the world's most respected brands.

image of each brand's logo

Faithfully serving IT professionals since 1996.

Experts Exchange Logo

Try it out and discover for yourself.

Subscribe Now

30-day free trial. Register in 60 seconds.

Related Solutions

  1. Adding a mask using Actionscript?
    Hi, I have a flash movie, which intends to dynamically place and animate images over the top of one another... this is currently being done by loading the images in dynmaically into a MovieClip object, which is created on-the-fly. That bit works fine. I also want these imag...
  2. masking with actionscript 3
    I have a movie clip on the stage. I want to attach a mask to it them animate the mask with AS3. Can someone gove me a basic example to get me started.
  3. How to zoom a movieclip with ActionScript 3
    Hello, I am new to ActionScript 3 - I'm trying to find a way to allow the user to zoom in and out of a movieclip, preferably using the slider component, with ActionScript 3. I've found some solutions using AS2 but since I'm new to this coding I don't know how to make this wo...
  4. AS3: How do I use button movieclips to load/unload othe…
    Hi there experts! I'm a newbie to AS3 and have limited experience in AS2. I'm having a tough time figuring out how to load/unload or addChild/removeChild movie clips dynamically on the main stage using AS3. The numerous tutorials I've come across on google seem to be using e...
  5. Error #1009 - Null object reference with "stage." in…
    Hi , I hope somebody can help me this is the last problem I have with my site before I can deliver and I've searched all over and tried so many things but haven't worked. I am getting this error with my event listener for checking if the browser is resized. My goal is to re...
  6. Actionscript AS3  tween movieclip on guide
    I'm writing in as3. I want to tween a movieclip along a guide. I have the guide drawn out and made into a guide layer. I have the movieclip linked to the layer beneath it. I want to tween the movieclip via actionscript so I can ease it, and also because it's smoother. How ...

Free Tech Articles

  1. WARNING: 5 Reasons why you should NEVER fix a computer for free.
    It is in our nature to love the puzzle. We are obsessed. The lot of us. We love puzzles. We love the challenge. We thrive on finding the answer. We hate disarray. It bothers us deep in our soul. W...
  2. SCCM OSD Basic troubleshooting
    SCCM 2007 OSD is a fantastic way to deploy operating systems, however, like most things SCCM issues can sometimes be difficult to resolve due to the sheer volume of logs to sift through and the dispe...
  3. Migrate Small Business Server 2003 to Exchange 2010 and Windows 2008 R2
    This guide is intended to provide step by step instructions on how to migrate from Small Business Server 2003 to Windows 2008 R2 with Exchange 2010. For this migration to work you will need the fo...
  4. Create a Win7 Gadget
    This article shows you how to create a simple "Gadget" -- a sort of mini-application supported by Windows 7 and Vista. Gadgets can be dropped anywhere on the desktop to provide instant information, ...
  5. Outlook continually prompting for username and password
    There have been a lot of questions recently regarding Outlook prompting for a username and password whilst using Exchange 2007. There are a few reasons why this would happen and I will try to cover t...
  6. Backup Exchange 2010 Information Store using Windows Backup
    There seems to be quite a lot of confusion around the ability to backup Exchange 2010 using the built in Windows Backup feature. This stems from the omission of this feature prior to Exchange 2007 s...

Cloud Class Webinars

  1. Avoiding Bugs in Microsoft Access
    Alison Balter takes and in-depth look at avoiding bugs in Access. In this webinar you will learn about using the immediate window to debug your applications, invoking the debugger, using breakpoints to troubleshoot, stepping through code, setting the next statement to execute, ...
  2. Top 10 Best New Features in Visio 2010
    Scott Helmers gives live demonstrations of the top 10 new features in Visio 2010. This webinar will teach you how to create compelling diagrams by adding shapes to the page with a single click, linking the shapes in a diagram to data in Excel (or SQL Server, or SharePoint), ...
  3. IT Consultant Business Secrets Revealed
    Michael Munger, Experts Exchange tech pro and IT consultant, pulls back the curtain on his very successful businesses and answers question on every IT consultant and business owner should know about. He shares secrets on what he did to solve the 5 most common problems in IT, ...
  4. Disaster Recovery and Business Continuity
    Quest CTO, Mike Billon, gives an overview of the steps involved in building a dunamic disaster recovery plan. Through case studies and an examination of software/hardware tooles for monitoring and testing, you'll gain a better understandin of where you are, where you want ...
  5. Organize Your Visio Diagrams with Containers and Lists
    Scott Helmers uses cross functional flowcharts, wireframe diagrams, data graphic legends and seating charts to teach you: how to ustilize all three new structured diagram components in Visio 2010, the best practices for organizeing shapes in previous version of Visio, how to organize ...
  6. How to Us Objects, Properties, Events and Methods in Microsoft Access
    Alison Dalter gives an in-depbth look at objects, properties, events and methods in Microsoft Access. In this webinar you will learn about using the object browser, referring to objects, working with properties and methods, working with object variables, understanding the ...

Join the Community

Give a Little. Get a Lot.

Join the community of experts here and help other tech pros by answering question in your area of expertise. You can earn FREE access to all Experts Exchange's premium features and resources.

Join the Community

Answers



by: blue-geniePosted on 2009-10-06 at 07:17:57ID: 25505286

hi if you're still wanting help can you upload your files.



by: dyaroshPosted on 2009-10-06 at 10:20:32ID: 25507430

Thanks for taking a look.  I've attached the flash file, xml file and pictures.  The flash file has the masked graphic in it.



by: blue-geniePosted on 2009-10-19 at 22:38:39ID: 25611261

picture class?



by: dyaroshPosted on 2009-10-20 at 09:52:02ID: 25616042

Sorry I missed it.



by: blue-geniePosted on 2009-10-20 at 23:29:52ID: 25621175

it looks like its a simple syntax error (i've just tested on the first loaded image)
you've got it right in terms of only trying to set the mask once the item is loaded but the syntax is mask =  not mask();

if (avg >= 1)
      {
            images_mc.visible = true;
            images_mc.mask = picMask;
            preload.removeEventListener(Event.ENTER_FRAME, preloading);
            removeChild(preload);

            // Change pictures every 5 seconds
            picTimer.start();

      }



by: dyaroshPosted on 2009-10-21 at 05:57:37ID: 25623412

Everything looks good except I lose the blue border around the picture.  Is there a way to keep it?



by: blue-geniePosted on 2009-10-21 at 22:42:58ID: 25631099

the border must not be part of the mask.
so make the border a separate thing ontop of the mask layer.



by: dyaroshPosted on 2009-10-26 at 06:50:00ID: 31636813

I'm not sure what you mean by your comment.  I'm going to accept your comment that got the mask working in VB Script since that was my initial question and open another question to solve the border problem.  If you are available to help me with the new question that would be great.
