Question

browser avoid "left" attribute - weird..

Asked by: Forrest_Gump

I put two divs (relative position) one with left:756px and the other with 252px.
for some reasons the browser draw the page  with the two divs with an error: the second div position is 467px relative instead of 252px!!!
what is the problem? how to fix it?

picture and code attached.

This Question has been solved and asker verified All Experts Exchange premium technology solutions are available to subscription members.

Subscribe now for full access to Experts Exchange and get

Instant Access to this Solution

  • Plus...
  • 30 Day FREE access, no risk, no obligation
  • Collaborate with the world's top tech experts
  • Unlimited access to our exclusive solution database
  • Never be left without tech help again

Subscribe Now

Asked On
2008-07-21 at 04:07:35ID23581393
Tags

css html

Topics

Cascading Style Sheets (CSS)

,

Internet Explorer Web Browser

,

Hypertext Markup Language (HTML)

Participating Experts
4
Points
500
Comments
13

Trusted by hundreds of thousands everyday for fast, accurate and reliable tech support.

  • "The time we save is the biggest benefit of Experts Exchange to Warner Bros. What could take multiple guys 2 hours or more each to find is accessed in around 15 minutes on Experts Exchange." Mike Kapnisakis, Warner Bros.
  • "Our team likes having a resource that is more secure than just using Google and most experts using this service really know their stuff. It's nice to look here first versus using Google." Dayna Sellner, Lockheed Martin
  • "Anytime that I've been stumped with a problem, 9 out of 10 times Experts Exchange has either the accepted solution or an open discussion of the potential solution to the problem." Kenny Red, eBay Inc.

See what Experts Exchange can do for you.

Got a question?

We've got the answer.

Experts Exchange has been collecting answers to technology questions since 1996…3 million and counting! If you have a question, chances are we already have your answer.

Screenshot of Experts Exchange Knowledgebase

Need individual assistance?

Our experts are ready to help.

If you can't find the exact answer you're looking for, ask our exclusive community of 50,000 experts. You’ll get a personalized answer from a trusted professional.

Screenshot of Experts Exchange Knowledgebase

Want to learn from the best?

Read articles from industry experts.

Thousands of free tech tips, tricks, how-to’s and tutorials are available in our peer reviewed articles section. See for yourself how smart our experts are, no login required.

Screenshot of an Article

Working on a long term project?

Store your work and research.

Save solutions to your questions, answers you’ve discovered through searching plus helpful articles in your personal knowledgebase for easy future access.

Screenshot of Experts Exchange Knowledgebase

Access the answers to your technology questions today.

Subscribe Now

30-day free trial. Register in 60 seconds.

What Makes Experts Exchange Unique?

Members of the expert community talk about why the experience at Experts Exchange is different than what you will find anywhere else.

Trusted by the world's most respected brands.

image of each brand's logo

Faithfully serving IT professionals since 1996.

Experts Exchange Logo

Try it out and discover for yourself.

Subscribe Now

30-day free trial. Register in 60 seconds.

Related Solutions

  1. Absolulte and Relative Positioning, and VML
    I've recently made a script for IE5+ only because I decided to use VML. What is basically does, is allows a user to click on an image and it will draw lines between the points clicked. It all works fine, except when I try to place elements on the place that aren't pos...
  2. <DIV> layer "relative" position
    Hi, I cannot figure out how to set the position of a <DIV> "relative" to that of another object etc... for instance... If i wanted to "float" the position of a <DIV> based on the Top+Height of another <DIV> etc... e.g. - defined in My.C...

Free Tech Articles

  1. WARNING: 5 Reasons why you should NEVER fix a computer for free.
    It is in our nature to love the puzzle. We are obsessed. The lot of us. We love puzzles. We love the challenge. We thrive on finding the answer. We hate disarray. It bothers us deep in our soul. W...
  2. SCCM OSD Basic troubleshooting
    SCCM 2007 OSD is a fantastic way to deploy operating systems, however, like most things SCCM issues can sometimes be difficult to resolve due to the sheer volume of logs to sift through and the dispe...
  3. Migrate Small Business Server 2003 to Exchange 2010 and Windows 2008 R2
    This guide is intended to provide step by step instructions on how to migrate from Small Business Server 2003 to Windows 2008 R2 with Exchange 2010. For this migration to work you will need the fo...
  4. Create a Win7 Gadget
    This article shows you how to create a simple "Gadget" -- a sort of mini-application supported by Windows 7 and Vista. Gadgets can be dropped anywhere on the desktop to provide instant information, ...
  5. Outlook continually prompting for username and password
    There have been a lot of questions recently regarding Outlook prompting for a username and password whilst using Exchange 2007. There are a few reasons why this would happen and I will try to cover t...
  6. Backup Exchange 2010 Information Store using Windows Backup
    There seems to be quite a lot of confusion around the ability to backup Exchange 2010 using the built in Windows Backup feature. This stems from the omission of this feature prior to Exchange 2007 s...

Cloud Class Webinars

  1. Avoiding Bugs in Microsoft Access
    Alison Balter takes and in-depth look at avoiding bugs in Access. In this webinar you will learn about using the immediate window to debug your applications, invoking the debugger, using breakpoints to troubleshoot, stepping through code, setting the next statement to execute, ...
  2. Top 10 Best New Features in Visio 2010
    Scott Helmers gives live demonstrations of the top 10 new features in Visio 2010. This webinar will teach you how to create compelling diagrams by adding shapes to the page with a single click, linking the shapes in a diagram to data in Excel (or SQL Server, or SharePoint), ...
  3. IT Consultant Business Secrets Revealed
    Michael Munger, Experts Exchange tech pro and IT consultant, pulls back the curtain on his very successful businesses and answers question on every IT consultant and business owner should know about. He shares secrets on what he did to solve the 5 most common problems in IT, ...
  4. Disaster Recovery and Business Continuity
    Quest CTO, Mike Billon, gives an overview of the steps involved in building a dunamic disaster recovery plan. Through case studies and an examination of software/hardware tooles for monitoring and testing, you'll gain a better understandin of where you are, where you want ...
  5. Organize Your Visio Diagrams with Containers and Lists
    Scott Helmers uses cross functional flowcharts, wireframe diagrams, data graphic legends and seating charts to teach you: how to ustilize all three new structured diagram components in Visio 2010, the best practices for organizeing shapes in previous version of Visio, how to organize ...
  6. How to Us Objects, Properties, Events and Methods in Microsoft Access
    Alison Dalter gives an in-depbth look at objects, properties, events and methods in Microsoft Access. In this webinar you will learn about using the object browser, referring to objects, working with properties and methods, working with object variables, understanding the ...

Join the Community

Give a Little. Get a Lot.

Join the community of experts here and help other tech pros by answering question in your area of expertise. You can earn FREE access to all Experts Exchange's premium features and resources.

Join the Community

Answers



by: nanharbisonPosted on 2008-07-21 at 04:37:55ID: 22049525

Can you please click on the "Attach Code Snippet" and copy and paste just the relevant code? It would be easier to read. Your tasks.txt file was huge and I think some of it was not necessary to see.
And can we see the css for these two divs? What are the names of these divs? You have a lot of them on this page so I don't know what I am looking for.
One thought - have you used overflow:hidden on the left div that you want to be overlapped with the next div.  I am not positive I understand the question you are asking.



by: mreuringPosted on 2008-07-21 at 05:38:15ID: 22049867

Without looking at the html, let me hazard a guess, the first div, at a guess would be 467 - 252 = 215 pixels wide?

Position: relative means that the element is displaced relative to its' original position in the flow of the document, I think that's what you were after. However, with that you must realize that its' original containing block is preserved within the flow of the document, unlike position: absolute where the element is removed from the flow of the document.

What you want to do is more likely achieved by giving the parent of these elements position: relative or absolute, whichever suits your needs (Judging from another q I was helping with I assume that your parent is already position absolute). When you give the two elements position:  absolute now they will be placed relative to the parent, which means that you can still use the same measurements you were using now.

Hope this is clear enough, if not let me know and I'll happily clarify :)

 Martin



by: mreuringPosted on 2008-07-21 at 05:51:07ID: 22049991

I just had a look at your html, using position: absolute on the eventsLayer seems to break this particular layout, where it didn't do so with the other Q. However, when I set the eventsLayer to position: relative and the divs to absolute it appears that they are placed as you intended.

I'm curious though, why the table when you're displacing the divs anyway?



by: Forrest_GumpPosted on 2008-07-21 at 13:53:57ID: 22054254

mreuring, tnx again for the help.
I havent find a time to apply your first solution (meetings day..), but I will do it now.
about this problem, I don't understand exactly what you ment.. Don't forget, I need this page work find under any resolution. using position:absolute won't work the same in different resolutions since I would have to specify left and top from the corner of the screen which isn't the same for all resolutions and screens.
Can you please explain your answer?

THANKS!!



by: TNamePosted on 2008-07-21 at 15:26:06ID: 22054899


Hi, just a remark - additionally to what mreuring said - I'm not sure if it is really understood what relative positioning really means. It might be a good idea to read different explanations, e.g.

    http://www.quirksmode.org/css/position.html
    http://www.autisticcuckoo.net/archive.php?id=2004/12/07/relatively-absolute
    http://www.christian-web-masters.com/articles/web_CSS-positioning-tutorial__page_1.html
    http://webdesign.about.com/od/advancedcss/a/aa061307.htm

In the picture you've posted, the div does exactly what it's told to do:
It is sitting 252px to the left and 33px down of it's normal position. And it's normal position is *in the upper left corner of it's parent* (a table cell), which itself is positioned well off the viewport's left margin.

If you give this parent cell a border, e.g.  style="border:1px solid #f00;"  and set the div's left and top to different values between 0 and 252px/33px,  you will better understand what's happening.

Giving the relevant elements (and their parents ;) borders and/or backgrounds just for testing - so that they become visible - can be very useful in order to understand the real structure of a page.
Also, tools like Firebug ( https://addons.mozilla.org/en-US/firefox/addon/1843 ) can prove very helpful.



by: scrathcyboyPosted on 2008-07-21 at 15:55:22ID: 22055146

The type of data you are displaying in your picture is best done in a table (since it is tabular data).

Why not remove the DIVs and the DIV-based CSS and work on adjusting the table.  It will be easier than trying to relative position a TABLE using pixel offsets in a DIV.  No wonder you are confused !!



by: Forrest_GumpPosted on 2008-07-21 at 16:36:49ID: 22055368

tnx TName,
The div is sitting 252px to the left but I told it to sit 467px!



by: TNamePosted on 2008-07-21 at 16:45:46ID: 22055420

Hm, that's strage - in the file I downloaded ("Tasks.txt") the left value for that div is defined as 252px.
Also, I cannot find a 467px value on the page...
A typo or a c/p error maybe?



by: Forrest_GumpPosted on 2008-07-21 at 17:22:40ID: 22055574

Sorry!
I mistake you.
I need the div to be in position 252, but it position 467.

In the picture I attach I mark by mistake the right edge of the left div instead of it's left edge.



by: mreuringPosted on 2008-07-21 at 19:44:33ID: 22056141

When you set an element to have 'position: absolute' all you're doing at that point in time it taking it out of the flow of the document. When you do not give that element a top, left, right and/or bottom value, that element will be exactly where it would have been had it still been in the flow of the document.

Additionally, an element with position: absolute does NOT get it's top/left/bottom/right from the canvas, or body-element. It get it's position in relation to its' positioned ancestor. In your case, giving your eventLayer position:absolute will not move the eventLayer from the position where it was drawn, if will however take that layer out of the flow of the document and place it on top of any following elements. By giving the layer position, the children of this layer will now be positioned in relation to the eventLayer, hence you can give them position: absolute and reliably position them, in relation to evenLayer.

I've tested your attached html and like I said, position: relative worked fine, but you must first solve http:Q_23579691.html because anything coming out of that question can have a lot of impact on what you're doing here...



by: Forrest_GumpPosted on 2008-07-21 at 23:11:01ID: 22056733

mreuring, lets summarize bot of the problems, tell me if this is what you propose:
1. For the first problem, add position:absolute; attribute to EventsLayer.
2. for the second problem, transform both of the divs position to absolute.

am I right?



by: mreuringPosted on 2008-07-31 at 04:31:41ID: 22128692

I am so sorry, I completely missed your last post. Your summary however was correct, so I hope that you have gone along with that and managed to solve this issue by now!!!

If not, and you're still looking for input, please let me know!

 Martin
