Refresh rate information xorg.conf monitor
I am running Ubuntu 7.04 and would like to setup my xorg.conf properly with my monitor. The monitor is a Compaq V710 and the problem I have is refresh rates. I would like to run 1152x864 @ 75 Hz (I know this is possible as I duel boot and that is what I run in Windows XP). How do I find out the correct refresh rate information to enter into xorg.conf because at the moment I can only run 1152x864 @ 66 or 67 Hz so I must have it wrong. Here is my xorg.conf:
Section "Device"
Identifier "nVidia Corporation NV17 [GeForce4 MX 440]"
Driver "nvidia"
Busid "PCI:1:0:0"
Option "AddARGBVisuals" "True"
Option "AddARGBGLXVisuals" "True"
Option "NoLogo" "True"
Option "UseEdidDpi" "FALSE"
Option "DPI" "96 x 96"
EndSection
Section "Monitor"
Identifier "Generic Monitor"
ModelName "COMPAQ V710"
Option "DPMS"
HorizSync 30 - 85
VertRefresh 50.0 - 160.0
DisplaySize 289 203
EndSection
Section "Screen"
Identifier "Default Screen"
Device "nVidia Corporation NV17 [GeForce4 MX 440]"
Monitor "Generic Monitor"
Defaultdepth 24
SubSection "Display"
Depth 1
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 4
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 8
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 15
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 16
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 24
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
EndSection
Oh and the graphics board device is no longer an "nVidia Corporation NV17 [GeForce4 MX 440]" I upgraded to a 6800 gs but am assuming that doesn't matter, if it does, how do I know what to put there instead?
Thank you
Simon
Section "Device"
Identifier "nVidia Corporation NV17 [GeForce4 MX 440]"
Driver "nvidia"
Busid "PCI:1:0:0"
Option "AddARGBVisuals" "True"
Option "AddARGBGLXVisuals" "True"
Option "NoLogo" "True"
Option "UseEdidDpi" "FALSE"
Option "DPI" "96 x 96"
EndSection
Section "Monitor"
Identifier "Generic Monitor"
ModelName "COMPAQ V710"
Option "DPMS"
HorizSync 30 - 85
VertRefresh 50.0 - 160.0
DisplaySize 289 203
EndSection
Section "Screen"
Identifier "Default Screen"
Device "nVidia Corporation NV17 [GeForce4 MX 440]"
Monitor "Generic Monitor"
Defaultdepth 24
SubSection "Display"
Depth 1
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 4
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 8
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 15
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 16
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
SubSection "Display"
Depth 24
Modes "1600x1200" "1280x1024" "1024x768" "800x600" "720x400" "640x480"
EndSubSection
EndSection
Oh and the graphics board device is no longer an "nVidia Corporation NV17 [GeForce4 MX 440]" I upgraded to a 6800 gs but am assuming that doesn't matter, if it does, how do I know what to put there instead?
Thank you
Simon
Asked:
2
2 Solutions
Re-running dpkg-reconfigure xserver-xorg tool in order to create new xorg.conf display configuration file (xorg.conf)
does not necessarily bring the best result since new calculation creates only basic file with no additional configuration informations.
And you need exactly that : an additional information about refresh rate(s) and corresponding screen resolutions you have to add
to your xorg.conf file .
The line(s) that are usually missing in basic/generic xorg.conf file refer to so called Modeline values that set correct refresh rate for each screen resolution you might wish to use with your monitor.
Linux ( and xorg developers) have created Modeline generators that calculate correct values for refresh rate you can later insert in your
xorg.conf file by manually editing file.
As I said you can try couple other tools ( besides dpkg-reconfigure xserver-xorg) as well to get more granular control over display configuration and I will give you the links to our very good modeline generators you can find on Internet .
very simple yet very accurate one : http://www.bohne-lang.de/spec/linux/modeline/
more precise xtiming generator: http://xtiming.sourceforge.net/cgi-bin/xtiming.pl
Zaph modeline generator: http://zaph.com/Modeline/
and Koala generator :http://koala.ilog.fr/cgi-bin/nph-colas-modelines
Refer to your Compaq V710 users manual to obtain manufacturers monitor specifications ( horizontal and vertical refresh and sync rates) fill corresponding boxes in WEB modeline generators. Don't forget selecting wrong refresh frequence can dammage your monitor
cathode ray tube.
Once you get modeline values as root launch your favorite text editor
and open /etc/X11/xorg.conf file for editing.
(REMEMBER to make xorg.conf backup file e.g. : cp /etc/X11/xorg.conf etc/X11/xorg.conf.old
COPY modeline you've got from modeline generator
( for example : Modeline "1024x768" 81.54 1024 1064 1168 1352 768 768 770 804 )
navigate to the line in xorg.conf file in your default colour depth section ( maybe 24 or 16 ) , PASTE the line and save file.
To activate new Xserver configuration press Ctrl+Alt+Backspace keys all at the same time ( keyboard shortcut for restarting Xserver).
good luck
and enjoy better screen refresh rate
does not necessarily bring the best result since new calculation creates only basic file with no additional configuration informations.
And you need exactly that : an additional information about refresh rate(s) and corresponding screen resolutions you have to add
to your xorg.conf file .
The line(s) that are usually missing in basic/generic xorg.conf file refer to so called Modeline values that set correct refresh rate for each screen resolution you might wish to use with your monitor.
Linux ( and xorg developers) have created Modeline generators that calculate correct values for refresh rate you can later insert in your
xorg.conf file by manually editing file.
As I said you can try couple other tools ( besides dpkg-reconfigure xserver-xorg) as well to get more granular control over display configuration and I will give you the links to our very good modeline generators you can find on Internet .
very simple yet very accurate one : http://www.bohne-lang.de/spec/linux/modeline/
more precise xtiming generator: http://xtiming.sourceforge.net/cgi-bin/xtiming.pl
Zaph modeline generator: http://zaph.com/Modeline/
and Koala generator :http://koala.ilog.fr/cgi-bin/nph-colas-modelines
Refer to your Compaq V710 users manual to obtain manufacturers monitor specifications ( horizontal and vertical refresh and sync rates) fill corresponding boxes in WEB modeline generators. Don't forget selecting wrong refresh frequence can dammage your monitor
cathode ray tube.
Once you get modeline values as root launch your favorite text editor
and open /etc/X11/xorg.conf file for editing.
(REMEMBER to make xorg.conf backup file e.g. : cp /etc/X11/xorg.conf etc/X11/xorg.conf.old
COPY modeline you've got from modeline generator
( for example : Modeline "1024x768" 81.54 1024 1064 1168 1352 768 768 770 804 )
navigate to the line in xorg.conf file in your default colour depth section ( maybe 24 or 16 ) , PASTE the line and save file.
To activate new Xserver configuration press Ctrl+Alt+Backspace keys all at the same time ( keyboard shortcut for restarting Xserver).
good luck
and enjoy better screen refresh rate
According to your current xorg.conf file your default colour depth is 24 ( millions of colours) .
If so you can add (insert) three modeline command lines ( labeled #600x1200@65Hz , #1600x1200@70Hz and 1600x1200@75Hz )
for 65 Hz , 70 Hz and 75 Hz refresh rates in
Section "Monitor"
right after line that reads : DisplaySize 289 203 and right before line that reads : EndSection:
ModeLine "1600x1200" 162.0 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
#1600x1200 @ 65Hz hsync: 81.3kHz
ModeLine "1600x1200" 175.5 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
# 1600x1200 @ 70Hz hsync: 87.5kHz
ModeLine "1600x1200" 189.0 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
# 1600x1200 @ 75Hz hsync: 93.8kHz
==========================
Note: this is only an example, you monitor might not be able to do 1664X1201 or 1856X1204 and 2160X1250 pixels resolutions
in 65-75 Hz refresh rates.
==========================
Ubuntu Linux specific xserver-xorg configuration steps:
http://ubuntuforums.org/showthread.php?t=83973
If so you can add (insert) three modeline command lines ( labeled #600x1200@65Hz , #1600x1200@70Hz and 1600x1200@75Hz )
for 65 Hz , 70 Hz and 75 Hz refresh rates in
Section "Monitor"
right after line that reads : DisplaySize 289 203 and right before line that reads : EndSection:
ModeLine "1600x1200" 162.0 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
#1600x1200 @ 65Hz hsync: 81.3kHz
ModeLine "1600x1200" 175.5 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
# 1600x1200 @ 70Hz hsync: 87.5kHz
ModeLine "1600x1200" 189.0 1600 1664 1856 2160 1200 1201 1204 1250 +hsync +vsync
# 1600x1200 @ 75Hz hsync: 93.8kHz
==========================
Note: this is only an example, you monitor might not be able to do 1664X1201 or 1856X1204 and 2160X1250 pixels resolutions
in 65-75 Hz refresh rates.
==========================
Ubuntu Linux specific xserver-xorg configuration steps:
http://ubuntuforums.org/showthread.php?t=83973
Thank you so much! I never really understood how to use mode lines properly. One thing that is a little confusing; the Gnome screen resolution changer caused me to think things weren't working for a while as it's refresh rate options seem to bear no relevance to anything, listed were rates like 50 and 54 etc. Checking the monitors OSD I realized it had worked. Could it be my xorg.conf is wrong?
Here it is if you don't mind taking a quick look:
Section "Monitor"
Identifier "Generic Monitor"
ModelName "COMPAQ V710"
Option "DPMS"
HorizSync 30 - 85
VertRefresh 50.0 - 160.0
DisplaySize 289 203
Modeline "800x600@120" 91.85 800 832 1176 1208 600 609 621 631
Modeline "1024x768@100" 126.64 1024 1056 1536 1568 768 781 794 807
Modeline "1152x864@85" 132.80 1152 1184 1688 1720 864 880 892 908
Modeline "1280x1024@75" 156.43 1280 1312 1904 1936 1024 1043 1056 1076
EndSection
Section "Screen"
Identifier "Default Screen"
Device "nVidia Corporation NV17 [GeForce4 MX 440]"
Monitor "Generic Monitor"
Defaultdepth 24
SubSection "Display"
Depth 1
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 4
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 8
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 15
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 16
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 24
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
EndSection
Thanks again
Simon
Here it is if you don't mind taking a quick look:
Section "Monitor"
Identifier "Generic Monitor"
ModelName "COMPAQ V710"
Option "DPMS"
HorizSync 30 - 85
VertRefresh 50.0 - 160.0
DisplaySize 289 203
Modeline "800x600@120" 91.85 800 832 1176 1208 600 609 621 631
Modeline "1024x768@100" 126.64 1024 1056 1536 1568 768 781 794 807
Modeline "1152x864@85" 132.80 1152 1184 1688 1720 864 880 892 908
Modeline "1280x1024@75" 156.43 1280 1312 1904 1936 1024 1043 1056 1076
EndSection
Section "Screen"
Identifier "Default Screen"
Device "nVidia Corporation NV17 [GeForce4 MX 440]"
Monitor "Generic Monitor"
Defaultdepth 24
SubSection "Display"
Depth 1
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 4
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 8
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 15
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 16
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
SubSection "Display"
Depth 24
Modes "1280x1024" "1152x864" "1024x768" "800x600"
EndSubSection
EndSection
Thanks again
Simon
Featured Post
Tackle projects and never again get stuck behind a technical roadblock.
Join Now
http://www.linuxconfig.org/Reconfigure_xorg_X_Window_System_on_debian_and_ubuntu
hope this helps
