<div>
Hi admitech,<br />
<br />
&nbsp;Apart from DHCP option 66, did you also set 67?<br />
&nbsp;Option 66 is only the server, 67 is the bootimage to use. Normally something like:<br />
&nbsp;boot\x86\pxeboot.com or boot\x64\pxeboot.com<br />
<br />
&nbsp;Regards,<br />
<br />
&nbsp;Luc
</div>


<div>
Luc:<br />
<br />
Thanks I did not. I was not sure what to put for my environment. Is this just generic and based upon x64/32/ia64, etc? Do I need option 60? If so how do I create it?<br />
<br />
Thanks so much!
</div>


<div>
<div class="content wysiwyg-content">
<b>Server</b>: 2012 R2<br />
<b>Mode</b>: Native<br />
<b>PXE</b>: Response set to respond to all then require approval for unknown...<br />
<b>Computer account location</b>: specified to same domain as WDS<br />
<b>Boot</b>: Set to Require the user to press F12 to continue the PXE boot<br />
<b>DHCP</b>: Do not listen on DHCP ports (tried all option for both check boxes)<br />
<b>Multicast:</b> Set to obtain IP address from DHCP<br />
<b><b>DHCP Authorization:</b> This is where it fails! Try to hit the box for &quot;Authorize this Windows Deployment Services server in DHCP. Tried dynamically and explicitly specifying the DC and GC. I get an error (see attached here)</b><br />
<b>Network: </b>Tried dynamic ports from Winsock and the default UDP ports.<br />
<br />
I tried setting up the DHCP scope options for the hostname of WDS. #60 is custom, how do I set this up or maybe I don't need it? The DHCP server and WDS and the client all can communicate but DHCP (clustered) and WDS are on different 2012 R2 servers.<br />
<a href="https://filedb.experts-exchange.com/incoming/2016/09_w40/1119655/WDSfail.PNG" target="_blank" class="file-inline" title="WDSfail.PNG (51 KB)"><svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512"><path d="M67.508 468.467c-58.005-58.013-58.016-151.92 0-209.943l225.011-225.04c44.643-44.645 117.279-44.645 161.92 0 44.743 44.749 44.753 117.186 0 161.944l-189.465 189.49c-31.41 31.413-82.518 31.412-113.926.001-31.479-31.482-31.49-82.453 0-113.944L311.51 110.491c4.687-4.687 12.286-4.687 16.972 0l16.967 16.971c4.685 4.686 4.685 12.283 0 16.969L184.983 304.917c-12.724 12.724-12.73 33.328 0 46.058 12.696 12.697 33.356 12.699 46.054-.001l189.465-189.489c25.987-25.989 25.994-68.06.001-94.056-25.931-25.934-68.119-25.932-94.049 0l-225.01 225.039c-39.249 39.252-39.258 102.795-.001 142.057 39.285 39.29 102.885 39.287 142.162-.028A739446.174 739446.174 0 0 1 439.497 238.49c4.686-4.687 12.282-4.684 16.969.004l16.967 16.971c4.685 4.686 4.689 12.279.004 16.965a755654.128 755654.128 0 0 0-195.881 195.996c-58.034 58.092-152.004 58.093-210.048.041z"/></svg>WDSfail.PNG</a>
</div>
</div>



Server: 2012 R2
Mode: Native
PXE: Response set to respond to all then require approval for unknown...
Computer account location: specified to same domain as WDS
Boot: Set to Require the user to press F12 to continue the PXE boot
DHCP: Do not listen on DHCP ports (tried all option for both check boxes)
Multicast: Set to obtain IP address from DHCP
DHCP Authorization: This is where it fails! Try to hit the box for "Authorize this Windows Deployment Services server in DHCP. Tried dynamically and explicitly specifying the DC and GC. I get an error (see attached here)
Network: Tried dynamic ports from Winsock and the default UDP ports.

I tried setting up the DHCP scope options for the hostname of WDS. #60 is custom, how do I set this up or maybe I don't need it? The DHCP server and WDS and the client all can communicate but DHCP (clustered) and WDS are on different 2012 R2 servers.

Windows Deployment Services not communicating to clients. DHCP server and WDS are on separate servers
